BR7000 Round Baler Specifications

New Holland 69 Baler Manual

BR7050 BR7060

MODEL

BR7050

BR7050

BR7060

BR7060

BR7060

BR7060

BALE SIZE

HIGH-MOISTURE

STANDARD

SILAGE SPECIAL

CROPCUTTER™

Diameter, in. (cm)

30-48 (76-122)

30-48 (76-122)

36-60 (92-152)

36-60 (92-152)

36-60 (92-152)

36-60 (92-152)

Width, in. (cm) ....................................................................................................................................

46.5 (118).....................................................................................................

Weight, lbs. (kg)

300-750 (136-340)

400-1000 (181-454)

400-1200 (181-544)

400-1200 (181-544)

400-1800 (181-816)

400-1800 (181-816)

Density pressure.......................................................................................

.........................................

Adjustable .....................................................................................................

BALER DIMENSIONS AND WEIGHT

Overall width, in. (cm)

85 (216)

85 (216)

85 (216)

95 (240)

95 (240)

95 (240)

Overall length (tailgate closed),

in. (cm)

135 (343)

135 (343)

185 (470)

185 (470)

185 (470)

185 (470)

Overalllength (tailgate open), in. (cm)

142 (361)

142 (361)

192 (488)

192 (488)

192 (488)

192 (488)

Overallheight (tailgate closed), in. (cm)

85 (216)

86 (218)

116 (295)

116 (295)

116 (295)

116 (295)

Overallheight (tailgate open), in. (cm)

127 (323)

127 (323)

158 (401)

158 (401)

158 (401)

158 (401)

Shipping weight, lbs. (kg)

2950 (1338)

3015 (1368)

4520 (2050)

5050 (2291)

5615 (2547)

6505 (2951)

Super Sweep™ PICKUP

Overall width, in. (cm)

60 (152)

60 (152)

60 (152)

N/A

N/A

N/A

Width tine-to-tine, in. (cm)

45 (113)

45 (113)

45 (113)

N/A

N/A

N/A

Width flare-to-flare, in. (cm)

53 (134)

53 (134)

53 (134)

N/A

N/A

N/A

Tine spacing, in. (cm)

2.6 (7)

2.6 (7)

2.6 (7)

N/A

N/A

N/A

Tine bars

4

4

4

N/A

N/A

N/A

Number of tines

72

72

72

N/A

N/A

N/A

Reel diameter, in. (cm)

16 (41)

16 (41)

16 (41)

N/A

N/A

N/A

Pickup protection

Adjustable slip clutch

Adjustableslip clutch

Adjustable slip clutch

N/A

N/A

N/A

WIDE PICKUP

Overall width, in. (cm)

N/A

N/A

N/A

77 (194)

77 (194)

N/A

Width tine-to-tine, in. (cm)

N/A

N/A

N/A

60 (153)

60 (153)

N/A

Width flare-to-flare, in. (cm)

N/A

N/A

N/A

69 (174)

69 (174)

N/A

Tine spacing, in. (cm)

N/A

N/A

N/A

2.6 (7)

2.6 (7)

N/A

Tine bars

N/A

N/A

N/A

4

4

N/A

Number of tines

N/A

N/A

N/A

96

96

N/A

Reel diameter, in. (cm)

N/A

N/A

N/A

10 (25)

10 (25)

N/A

Pickup protection

N/A

N/A

N/A

Adjustable

Adjustable

N/A

ratchet clutch

ratchet clutch

XtraSweep™ PICKUP (1.8M)

Overall width, in. (cm)

N/A

N/A

N/A

84 (213)

84 (213)

N/A

Width tine-to-tine, in. (cm)

N/A

N/A

N/A

71 (181)

71 (181)

N/A

Width flare-to-flare, in. (cm)

N/A

N/A

N/A

79 (201)

79 (201)

N/A

Tine spacing, in. (cm)

N/A

N/A

N/A

2.6 (7)

2.6 (7)

N/A

Tine bars

N/A

N/A

N/A

4

4

N/A

Number of tines

N/A

N/A

N/A

112

112

N/A

Reel diameter, in. (cm)

N/A

N/A

N/A

12 (31)

12 (31)

N/A

Pickup protection

N/A

N/A

N/A

Adjustable

Adjustable

N/A

ratchet clutch

ratchet clutch

XtraSweep PICKUP (2.07M)

Overall width, in. (cm)

N/A

N/A

N/A

N/A

N/A

94 (240)

Width tine-to-tine, in. (cm)

N/A

N/A

N/A

N/A

N/A

82 (207)

Width flare-to-flare, in. (cm)

N/A

N/A

N/A

N/A

N/A

90 (228)

Tine spacing, in. (cm)

N/A

N/A

N/A

N/A

N/A

2.6 (7)

Tine bars

N/A

N/A

N/A

N/A

N/A

4

Number of tines

N/A

N/A

N/A

N/A

N/A

128

Reel diameter, in. (cm)

N/A

N/A

N/A

N/A

N/A

12 (31)

Pickup protection

N/A

N/A

N/A

N/A

N/A

Shearbolt

New

New Holland

BR7000 Round Baler Specifications

BR7050 BR7060

MODEL

BR7050

BR7050

BR7060

BR7060

BR7060

BR7060

BALE FORMING CHAMBER

HIGH-MOISTURE

STANDARD

SILAGE SPECIAL

CROPCUTTER™

Floor roll, in. (cm)..................................................................................................................................

12 (31) .......................................................................................................

Forming rolls, in. (cm)

2 rolls, 10 (25)

2 rolls, 10 (25)

3 rolls, 10 (25)

3 rolls, 10 (25)

3 rolls, 10 (25)

3 rolls, 10 (25)

Stripper roll ................................................................................................

.................................

Embossed surface...............................................................................................

Starter roll, in. (cm)

Embossed surface

Embossed surface

7 (17)

7 (17)

7 (17)

7 (17)

Steel looped sledge follower roll

N/A

N/A

N/A

N/A

Standard

Standard

Tailgate nose roll

N/A

Standard

N/A

N/A

Standard

Standard

Rubber backwrap roll

N/A

Standard

N/A

N/A

Standard

Standard

BELTS

Number of belts .........................................................................................................................................

6 ............................................................................................................

Width, in. (cm).........................................................................................................................................

7 (18) ........................................................................................................

Length, in. (cm)

273 (692)

273 (692)

343 (871)

343 (871)

343 (871)

343 (871)

Surface.............................................................................................................................................

Mini-rough top .................................................................................................

Endless belts

N/A

N/A

N/A

N/A

Standard

Standard

TWINE SYSTEM

Twine application

One pivoting arm

One pivoting arm

Dual pivoting arms

Dual pivoting arms

Dual pivoting arms

Dual pivoting arms

Twine control

Electric toggleswitch

Electric toggleswitch

Automatic

Automatic

Automatic

Automatic

Twine storage capacity

4 balls

4 balls

6 balls

6 balls

6 balls

6 balls

OVER-THE-EDGE WRAPPING

EdgeWrap™

N/A

N/A

N/A

Available

Available

Available

BALE FORMING INIDCATORS

Bale size.................................................................................................................................................

Standard......................................................................................................

Driving gauges

N/A

N/A

N/A

Standard

Standard

Standard

Twine movement..................................................................................................................................

Standard......................................................................................................

Twine arm position ..............................................................................................................................

Standard......................................................................................................

Bale counter................................................................................................

..........................................

Standard......................................................................................................

Bale ejector ............................................................................................................................................

Standard......................................................................................................

Hydrualic pressure gauge

N/A

N/A

Standard

Standard

Standard

Standard

Tailgate latch.........................................................................................................................................

Standard......................................................................................................

TRACTOR REQUIREMENTS

PTO hp (minimum), hp (kW)

40 (30)

45 (33)

60 (45)

60 (45)

65 (48)

100 (75)

PTO speed (rpm) .......................................................................................................................................

540 ..........................................................................................................

PTO protection

Shearbolt

Shearbolt

Shearbolt

Slip Clutch

Slip Clutch

Cutout Clutch

Hydrualic remote requirement

1

1

1 - 2

1 - 2

1 - 2

3 - 4

Implement Alley Discussion Board
[ View Follow Ups ] [ Post Followup ] [ Return to Forum ]
New holland super 69 balerParts

Posted by James on October 13, 2002 at 19:49:04 from (216.117.85.84):

I've tried (to no avail) suggesting to YT that a page be set up for dating and describing different makes and models of equipment. I know you guys have all the information needed, we just need to get it all together in one spot. Let's start with New Holland balers. If you look back through the history, you see someone is asking nearly every day about a different model of baler. They are asking how old, what size, good and bad points etc. I've got the same questions and would love to see the answers in one place. Can you guys please help me out? (Noteably Steve from N.H. Pa: I've seen you saying you could go on and on about NH balers, here's your chance. I'm asking you to go on and on!)

Model #65 1960-1965 14x16 bales
#66 '52-'55 14x16 wadboard feeder instead of aluminum fingers-ve wood on plunger-ve
#67 '58-'61 14x16
#68 '56-'58 14x16 wood on plunger-ve
#69 ?

Some of the above balers had wooden parts on their plungers(-ve means this is an undesirable item) However, most of these models were available as a Super: all Supers have rollers instead of wood on their plungers.
#S66
#S67 What else does Super mean?
#S68
#S69

#268 '64-'68 14x16 very good baler, but slow
#269 '64-'68 same as #268 except longer tongue with extra U-joint.+ve
#270 '61-'63 14x16
#271 '61-'63 same as #270 with longer tongue and extra U-joint+ve
#272 '64-'68 14x16 very good, but slow
#273 '72-'77 14x16 very good, but slow
#275 ?
#276 '72-'76
#278 ?
#279 ?

New Holland 69 Baler Specifications

All balers models started after 1963 had the longer tongue with the extra U-joint(3 total)for better turning ability.

The above balers were made to run at 61-66 plunger strokes per minute which makes them 'low capacity' compared to some later balers which were made to run much faster.

A Super Sweep pick-up was optional on some of these balers. The Super Sweep has 6 bars of teeth instead of 4, and has more teeth closer together than the standard pick-up. The Super Sweep works better with less waste than the standard pick-up.

#310 '78-'82 14x16 nearly same as #273 except designed to run at 75 strokes per minute (spm) instead of 66spm like the 273. Feeder track assemblies blow apart at this speed, and some plungers will break. Should be ran 20% below recommended speed.
#311 '75-'89 14x16 followed #310 Great baler because it was designed to withstand it's recommended strokes per minute(spm)
#315 '75-'82 14x16 see #310 should be ran 20% below recommended speed
#316 see #311 followed #315 great baler
#320 Super high capacity see #310 recommended 105 spm should only be ran at 90 spm
#326 see #311 followed #320 great baler

New Holland 69 Baler Parts


That's all I know at this time. Please feel free to add or make corrections. Let's complete the entire list detailing any options, good and bad points. Then we will see if YT will consider the idea for other implements and/or tractors.

Follow Ups:

  • Re: Complete rundown on New Holland BalersJohn2510-302018:53:07 10/20/02(0)
  • Re: Complete rundown on New Holland BalersJames17:18:25 10/16/02(0)
  • Re: Complete rundown on New Holland Balersgw holland12:03:54 10/16/02(0)
  • Re: Complete rundown on New Holland BalersErnie Bob22:20:27 10/15/02(1)
    • Re: Re: Complete rundown on New Holland BalersNHBalerman19:42:20 10/16/02(0)
  • Re: Complete rundown on New Holland BalersBurrhead15:59:39 10/15/02(7)
    • Re: Re: Complete rundown on New Holland BalersKelly C05:20:35 10/16/02(6)
      • Re: Re: Re: Complete rundown on New Holland BalersBurrhead14:19:13 10/16/02(5)
        • Re: Re: Re: Re: Complete rundown on New Holland BalersKelly C14:48:58 10/16/02(4)
          • Re: Re: Re: Re: Re: Complete rundown on New Holland BalersBurrhead19:39:13 10/16/02(3)
            • Re: Re: Re: Re: Re: Re: Complete rundown on New Holland BalersKelly C20:10:17 10/16/02(1)
              • Re: Re: Re: Re: Re: Re: Re: Complete rundown on New Holland BalersLINDA 21:16:12 05/12/03(0)
            • Re: Re: Re: Re: Re: Re: Complete rundown on New Holland BalersKelly C20:07:47 10/16/02(0)
  • Re: Complete rundown on New Holland BalersBrandon12:50:33 10/15/02(0)
  • Re: Complete rundown on New Holland BalersScott18:07:57 10/14/02(0)
  • Re: Complete rundown on New Holland Balerslatta08:32:36 10/14/02(1)
    • Re: Re: Complete rundown on New Holland BalersJames15:21:07 10/14/02(0)
  • Re: Complete rundown on New Holland BalersMichael07:58:32 10/14/02(0)
  • Re: Complete rundown on New Holland BalersTom A -- THANKS!07:17:06 10/14/02(0)


Post A Followup

:
:

: Re: Complete rundown on New Holland Balers

:

:

:

:

: If you check this box, email will be sent to you whenever someone replies to this message. Your email address must be entered above to receive notification. This notification will be cancelled automatically after 2 weeks.

TRACTOR PARTS TRACTOR MANUALS
Parts for new holland baler
We sell tractor parts! We have the parts you need to repair your tractor - the right parts. Our low prices and years of research make us your best choice when you need parts. Shop Online Today. [ About Us ]
Home | Forums

Today's Featured Article - Memories of an IH Super A When I was ? up to 10, I worked on my Papaw's farm in Greeneville, TN every summer. As I grew older (7), it was the thrill of my day to ride or drive on the tractor. My Papaw had a 1954 IH Super A that he bought to replace a Cub. My Papaw raised 'baccer' (tobacco) and corn with the Super A, but the fondest memory was of the sawmill. He owned a small sawmill for sawing 'baccer' sticks. The Super A was the powerplant. When I was old enough (7 or 8), I would get up early and be dressed to ... [Read Article]
Latest Ad: farmall cub manifold[More Ads]

68 New Holland Baler Parts

Copyright © 1997-2020 Yesterday's Tractor Co.

All Rights Reserved. Reproduction of any part of this website, including design and content, without written permission is strictly prohibited. Trade Marks and Trade Names contained and used in this Website are those of others, and are used in this Website in a descriptive sense to refer to the products of others. Use of this Web site constitutes acceptance of our User Agreement and Privacy Policy

TRADEMARK DISCLAIMER: Tradenames and Trademarks referred to within Yesterday's Tractor Co. products and within the Yesterday's Tractor Co. websites are the property of their respective trademark holders. None of these trademark holders are affiliated with Yesterday's Tractor Co., our products, or our website nor are we sponsored by them. John Deere and its logos are the registered trademarks of the John Deere Corporation. Agco, Agco Allis, White, Massey Ferguson and their logos are the registered trademarks of AGCO Corporation. Case, Case-IH, Farmall, International Harvester, New Holland and their logos are registered trademarks of CNH Global N.V.

Yesterday's Tractors - Antique Tractor Headquarters




Coments are closed
